HT818 Administration Guide
Version 1.0.27.2
address will be changed based on the network mask -- the effective subnet will
be increased by 1.
For example; 192.168.2.1 will be changed to 192.168.3.1 if net mask is
255.255.255.0. Then the device will reboot
Default value is 100. The last segment of IP address assigned to the HT818 in
the LAN Network.
Default configuration assigns IP address (to local network devices) starting from
192.168.2.100.
Default value is 199. This parameter allows a user to limit the number of local
network devices connected to the internal router.
Default configuration assigns IP address (to devices connected to the LAN port)
in a range from 192.168.2.100 up to 192.168.2.199.
Sets the LAN subnet mask. Default value is 255.255.255.0
Default value is 120 hrs (5 days). The length of time the IP address is assigned
to the LAN clients. Value is set in units of hours.
This function forwards all WAN IP traffic to a specific IP address if no matching
port is used by HT818 or in the defined port forwarding.
Forwards a matching (TCP/UDP) port to a specific LAN IP address with a specific
(TCP/UDP) port. Up to 8 rules are available.
Gives the administrator the option to restore default configuration on the HT818.
There are 3 types of factory reset:
• ISP Data Reset: All VoIP related configuration (mainly everything located on
FXS page).
• VoIP Data Reset: All ISP (Internet Service Provider) configuration which may
affect the IP address.
• Full Reset: Both VoIP and ISP related configuration at the same time.
Note: After choosing reset type, you will have to click the reset button for it to take
effect.
