Using Extension Boards and MPKs
Users have also the ability to set presence watcher on phone MPKs (Multi-purpose Keys), and connected
Extension Boards.
For MPKs configuration, similarly to the VMPKs configuration, you need to have a phone supporting
Physical Multi-Purpose Keys. For instance, GXP2130 / GXP2160 / GXP1628 are offering physical MPKs,
and you can do the same configuration for Presence Watcher. This is available on phone Web
UISettingsProgrammable KeysPhysical Multi-Purpose Keys.
Note: Using Physical MPKs, the Presence Watcher feature will be limited in comparison with VMPKs. The
six available Presence Statuses will have the following LED states when using MPKs:
Table 5: MPKs LED States
Available, Custom Status, Away
Users can also use Extension Boards for Presence Watcher configuration, for example GXP2140 and
GXP2170 support Extension Boards (GXP2200Ext), the extension board configuration is available under
web UISettingsExtension Boards.
Following are examples of LED status on extension boards:
Available DND Unavailable
Figure 12 : Ext Presence Status
