Grant Vortex Eco Series Installation And Servicing Instructions

Page 17
Heating Flow
Heating Return
Thermostat Phials
Air Vents
Figure 5-4: Vortex Eco External System 26/35 water connections
and thermostat phial positions
Figure 5-1: Vortex Eco External 15/21 and 21/26 water
connections and thermostat phial positions
Heating Flow
Heating Return
Air Vent
Thermostat
Phials
Heating Flow
Heating Return
Thermostat
phials
Air Vent
Figure 5-2: Vortex Eco External 26/35 water connections and
thermostat phial positions
Heating Flow
Heating Return
Thermostat Phials
Air Vents
Figure 5-3: Vortex Eco External System 15/21 and 21/26 water
connections and thermostat phial positions
5.3 WATER CONNECTIONS AND THERMOSTAT PHIAL POSITIONS
Section 5: Pipe Connections
