26
9. Fit the cable with connector, which is supplied with the pump,
to the pumps electrical connection box.
10. Fit the new pump and tighten the retaining screws.
11. Connect the pump to the tubes using new hose clamps and
connect the electrical connector.
12. Refit all cover plates.
13. Reposition the machine and turn on the water supply.
14. Turn on electrical supply and water supply.
15. Refill the machine. Make at least one test run. Check for leaks.
Check that no error codes are issued. Normal rinse time should
be 40 seconds. Alarm is issued after 50 seconds.
1. If error code is issued perform “Cleaning of rinse system”
c. Exchange of heating element rinse tank
1. Turn off hot water supply and electrical supply.
2. Run the rinse pump using Flashloader software to empty the
rinse tank
3. Empty the last water through the rinse plug. Deflect the water
out of the machine. ( Caution content may be hot. )
2
5
6
L1
L2
L3
