12 Creative Grading Camera Control System User’s Guide (v1.4)
Chapter 2 - Installation
• Tablet computer — Apple iPad (at least a 6th generation device running iOS 13 or higher)
with Apple Ethernet connection and powering hardware.
• Ethernet switch — equipped with enough ports for the total amount of CGPs. A Power
over Ethernet (PoE) switch is recommended.
• Power supply unit — for each CGP if Power over Ethernet is not used.
• Ethernet UTP cables.
2.2 Installing the CCS-ONE Cameras Control Server
2.2.1 Connecting the server
• Attach a monitor via HDMI and a mouse and keyboard via USB to the CCS-ONE (monitor,
mouse and keyboard are not delivered with the product).
• Connect power (use the power supply that is shipped with the product) to the DC Input of
the CCS-ONE. By default the server powers up automatically after power is applied.
2.2.2 Setting up the server
• In the Windows start screen, log in with admin as the user name and enter admin as the
password.
• Go to Start on the taskbar and go to Settings > Network & Internet > View your
network properties and locate the IP (IPv4) settings of the LAN Public network interface.
Copy or write down these settings for later use when installing the CGA app.
2.2.3 Setting up the network
• Connect an Ethernet switch to the C2IP Ethernet port of the CCS-ONE. Connect CGPs to
this switch.
When CGPs, XCUs and/or a CCS-ONE are located in seperate LAN (or VLAN) networks, a C2IP
Nameserver is required to establish connections between devices in the different networks.
It is allowed to use more than one CCS-ONE server in a camera control system but the servers
operate individually, unaware of each other.
2.2.4 Adding a storage USB Flash Drive
As external storage space, a USB Flash Drive can be inserted into a free USB port. The USB
Flash Drive can be used in the CGA to store camera files and/or CGP configurations. Refer to
the chapter “CGA Operation” on page 21 for more information about using external storage.
