19
LUBRICATION AND MAINTENANCE
CAPACITIES
Fuel Tank .......................... 4.3 U.S. gal. (16.3 l)
H
2
Drive System ..................2.5 U.S. qt. (2.37 l)
Drive System Fluid Change
approx. ............2.0 U.S. qt. (1.89 l)
TIRE AIR PRESSURE
Drive Tires
Standard 22 x 11 x 10 ..............8 psi (55 kPa)
Optional 22 x 10 x 10 ...............8 psi (55 kPa)
(refer to decal on wheel for correct tire air
pressure)
Rear Tires .............. 12 to 15 psi (83 to 103 kPa)
H
2
DRIVE SYSTEM
Fluid Change ................................... 1000 hours
Filter Change ................................... 1000 hours
CRANKCASE OIL AND AIR
FILTER
Refer to the “Engine Manual” for the time table
for changing or service.
COOLING SYSTEM
Remove and clean radiator screen regularly. A
dirty screen will cause the engine to overheat.
Do not use high pressure water or
steam to clean the engine or drive
compartment. Water and clean-
ing detergent may damage electrical
components and terminals, possibly
leading to component and safety cir-
cuit failure.
Use a vacuum cleaner or air blower to remove
foreign material from the engine and drive com-
partment.
Check engine coolant when the engine is cool. If
coolant is required, fi ll expansion tank to proper
level through radiator. A solution of 50% anti-
freeze and 50% water must be used (freezing
point about –34° F [–36° C]). Do not use 100%
antifreeze or severe damage will occur.
WARNING
CAUTION
CAUTION
Always wear safety glasses and ear
protection when performing any
maintenance function that could cause
injury to eyes or ears.
Read all safety information on pages 6 through
10.
Lower attachment to ground, shut off
tractor engine, remove key and wires
to fuel solenoid before performing any
maintenance.
LUBRICATION
Do not let excess grease collect on or around
parts, particularly when operating in sandy ar-
eas.
The chart gives the frequency of lubrication
in operating hours based on normal operating
conditions. Severe or unusual conditions may
require more frequent lubrication.
Use an SAE multipurpose type grease for all
locations shown. Be sure to clean fi tting thor-
oughly before using grease gun.
For H
2
Drive System, use Grasshopper Fluid,
part no. 345050 for 1 quart (.94 l) container or
part no. 345055 for 1 gallon (3.76 l) container.
Lubricate Every Lubricate Every
8 Hours of Usage 80 Hours of Usage
Rear Wheel Bearings Clutch Power Shaft
(two fi tting) (two fi ttings)
Drive Shaft
(one fi tting)
To Next Page
