5
SPECIFICATIONS
721D H
2
Engine Kubota three cylinder
4 cycle liquid cooled
Model No. D722
Horsepower (G.I.H.P.) 20.9 (15.6 kw)
Displacement 44 cu. in. (719 cc)
No-load rpm 3600
Charging System 12VDC 12.5 amp.
negative ground
Starter Electric
Electrical System Safety interlocked
PTO 3100 r.p.m. (max.)
Electric clutch
Transmission H
2
dual path
hydrostatic direct drive
Steering Dual levers independently
control speed and direction
of travel.
Zero turning radius (center of
machine is pivot point).
Speed
Forward (variable) 0 to 9 m.p.h. (14.5 km/h)
Reverse (variable) 0 to 6 m.p.h. (9.6 km/h)
Fuel Tank Capacity 4.3 U.S. gal. (16.3 l)
Tire Sizes
Front Drive Wheels
Standard 22 x 11 x 10 - 4 ply rated
Optional 22 x 10 x 10 - 4 ply rated
Tail Wheel 13 x 6.50 x 6 rib - 4 ply rated
Dimensions of Tractor
Seat Back Height 46" (1.17 m)
Seat Cushion Height 30.5" (.78 m)
Tractor Width 50.0" (1.26 m)
Tractor Length 78" (1.98 m)
Wheel Base 49.5" (1.26 m)
Weight - Uncrated 920 lbs. (416.8 kg)
Weight - Crated 1030 lbs. (467.0 kg)
Hour Meter Standard
