Grasshopper 723T User Manual

28
TRACTOR ASSEMBLY - 727T
6
1 644873 Lower Frame
2 644874 Upper Frame
3 253192 Whiz Bolt .312-18 x .75
4 253035 Whiz Nut .312-18
5 780900 Tension Rod
6 253200 Whiz Bolt .375-16 x .75
7 182253 Work Lamp
8 182251 Bezel – Snap Mount
9 253203 Whiz Bolt .375-16 x 1 Lg. Flange
10 603821 Throttle Assembly
(includes cable assembly)
323655 Cable Assembly
722009 Throttle Lever Stop
11 422150 Handle Grip
12 902280 Spacer
243335 Bolt .375-16 x 1.25
257040 Washer .375
13 422040 Tool Box
14 693210 Fender Rt.
15 693211 Fender Lt.
16 822635 Trim – Fender Edge
17 722062 Cover Panel - Right Fender
18 483942 Wheel & Tire 22 x 11 x 10
Bar Tread Rt.
19 483943 Wheel & Tire 22 x 11 x 10
Bar Tread Lt.
482483 Tire 22 x 11 x 10 Bar Tread
483420 Wheel 10.00
483946 Wheel & Tire 22 x 10 x 10
Turf Tread (optional)
482473 Tire 22 x 10 x 10 Turf Tread
20 100190 Engine - 27 HP Kohler
900117 Engine Shim (as required)
21 100802 Oil Filter
22 100936 Air Filter – Outer Element
100937 Air Filter – Inner Element
23 722975 Shield – Coupler
24 101217 Muffler
101041 Exhaust Gasket
25 101001 Fuel Filter
26 605125 Bracket – Shield Mount
(includes item 73)
27 729270 Bracket – Lower Muffler
28 722309 Inner Panel – Shield
29 722391 Muffler Shield
30 693100 Console
31 721152 Console Fill Panel
32 142233 Mechanical Choke Cable
33 604844 Fuel Tank Assembly
34 141144 Gauge – Fuel
424275 Grommet – Fuel Gauge
35 100210 Cap - Fuel
36 101875 Bushing – Fuel Tube
37 363928 Fuel Tube .25
38 821710 Fuel Line Hose
39 280260 Hose Clamp .25
40 323933 Counterweight – 34 #
41 729514 Weight Cover Plate
42 247325 Bolt .375 x 5.5 Carriage
43 643092 Deck Mount Rt.
44 643093 Deck Mount Lt.
45 247280 Bolt .375-16 x 2.75 Carriage Special
46 282575 Deck Mount Bushing
47 282576 Deck Mount Bushing – Floating (opt.)
48 253460 Nut .375-16 Nylon Insert
49 604346 Foot Rest w/Tread, Bearing, & Blocks
50 420905 Foot Platform Tread
51 422615 Nylon Bushing
52 780673 Threaded Rod – Foot Platform
53 253470 Nut .5-13 Nylon Insert
54 424052 Rubber Bumper
55 603301 Foot Platform Extension
56 420904 Foot Platform Extension Tread
57 247130 Carriage Bolt .312-18 x .75
58 644826 Tank Mount - 8 Gallon
59 721181 Heat Shield - 8 Gallon
60 283312 Compression Spring
61 424100 Foot Rest Block
62 243026 Tap Screw .25 x 1
63 253043 Whiz Nut .375-16
64 644099 Battery Box
65 644162 Battery Cover
66 427273 Pad – Battery Tray
67 729001 Battery Clamp
68 257020 Washer .25
253440 Nut .25-20 Nylon Insert
69 253175 Whiz Bolt .25-20 x .75
70 253025 Whiz Nut .25-20
71 253173 Whiz Bolt .25-20 x .5 Hex
72 253176 Whiz Bolt .25-20 x .5 Truss
73 254431 Speed Nut .25-20
74 424015 Rubber Bumper
75 422065 Square Plug 1"
76 364518 Nipple .375 x 2.5
77 143610 Valve – Oil Drain
78 363855 Fitting .375 NPT Female .375 Barb 90°
79 248565 Lug Bolt .5-20 x .875
80 723339 Tank Shield - 8 Gallon
Item not pictured:
605335 Decal Set - 727T
6
Tractor
08004
Rev. 01-08
ItemItem
ItemItem
Item
OrderOrder
OrderOrder
Order
DescriptionDescription
DescriptionDescription
Description
No.No.
No.No.
No.
No.No.
No.No.
No.
ItemItem
ItemItem
Item
OrderOrder
OrderOrder
Order
DescriptionDescription
DescriptionDescription
Description
No.No.
No.No.
No.
No.No.
No.No.
No.
