Grasshopper 723T User Manual

STANDARD UNIVERSAL HARNESS
(ALL HYDRAULIC LIFT MODELS)
05065
1
2
THIS CONNECTOR STAYS
WITH TRACTOR
BROWN
TO PTO CLUTCH SWITCH
CONNECTOR
EXISTING PTO CLUTCH
FROM WIRING HARNESS
EXISTING CONNECTOR
TO
ENGINE
GROUND
GREEN
THIS CONNECTOR COMES
WITH THE
ACCESSORY HARNESS
PURPLE
GREEN/YELLOW
6 WAY WEATHER-PACK
CONNECTOR
FEMALE TERMINALS
05065
REAR CORNER OF FRAME
RELAY MOUNTS IN LEFT
BLACK
GREEN
BROWN
BROWN
6 WAY WEATHER-PACK
CONNECTOR
MALE TERMINALS
HYDRAULIC DECK
LIFT SOLENOID
EXISTING WIRE
TO DECK LIFT
SWITCH
BROWN
RED/WHITE
GREEN/YELLOW
CLUTCH
BROWN
CE
A
40
B
A
C
B
F
DE
FD
605959 Universal Harness
1 181475 Fuse Auto - 40 Amp.
2 184271 Relay
ItemItem
ItemItem
Item
OrderOrder
OrderOrder
Order
DescriptionDescription
DescriptionDescription
Description
No.No.
No.No.
No.
No.No.
No.No.
No.
48
