32
ItemItem
ItemItem
Item
OrderOrder
OrderOrder
Order
DescriptionDescription
DescriptionDescription
Description
No.No.
No.No.
No.
No.No.
No.No.
No.
ItemItem
ItemItem
Item
OrderOrder
OrderOrder
Order
DescriptionDescription
DescriptionDescription
Description
No.No.
No.No.
No.
No.No.
No.No.
No.
BRAKE ASSEMBLY
01-07062
Rev. 01-08
*To determine CW or CCW, hold the brake as-
sembly in hand with the ribs on brake facing
toward you and the lever in the disengaged posi-
tion. The direction of rotation of lever, when
engaging brake, determines CW or CCW.
1 603611 Wheel Motor Assembly (723T)
(includes items 2 - 4)
603614 Wheel Motor Assembly (727T
6
)
2 604442 Hub & Rotor Assembly
775192 Brake Rotor – 8.0
259592 Socket Head Screw
3 254522 Jam Nut 1-20 w/Nylok
4 281860 Woodruff Key .312 x 1
5 248565 Lug Bolt .5-20 x .875
6 902299 Spacer – Wheel Motor
7 243622 Sq Head Bolt .5-13 x 4
8 257432 Lock Washer .5
9 254470 Nut .5-13
10 776274 Mount – Brake & Traction Kit
11 644588 Mount – Brake Caliper
12 481102 Caliper Brake Assembly – CW*
603150 Brake Pad Kit
13 481103 Caliper Brake Assembly – CCW*
603150 Brake Pad Kit
14 247130 Carriage Bolt .312-18 x .75
15 253035 Whiz Nut .312-18
16 644539 Brake Pivot Tube
17 732617 Mount – Brake Pivot
18 253200 Whiz Bolt .375-16 x .75
19 253043 Whiz Nut .375-16
20 644035 Brake Lever
21 422150 Handle Grip
22 644036 Arm – Brake Linkage
23 265537 Clevis Yoke .312-24 x 2.5
24 254441 Nut .312-24
25 780158 Linkage Rod – Brake
26 265615 Ball Joint .312-24 RH Thread
27 880926 Linkage Pin – Brake
28 260606 Ring Cotter .047 x .312
29 243030 Bolt .25-20 x 1.25
30 243340 Bolt .375-16 x 1.5
31 257040 Washer .375
32 902280 Spacer
33 183894 Brake Switch
34 261284 Clevis Pin .312-18 x 1
35 257020 Washer .25
36 253038 Whiz Nut .312-24
37 881130 Spacer – Brake Lever
38 257063 Nylon Washer .50 ID
39 257030 Washer .312
40 253025 Whiz Nut .25-20
41 782851 Brake Strap
42 243195 Bolt .312-18 x .75
To Next Page
