Grasshopper 723T User Manual

30
DRIVE ASSEMBLY
ItemItem
ItemItem
Item
OrderOrder
OrderOrder
Order
DescriptionDescription
DescriptionDescription
Description
No.No.
No.No.
No.
No.No.
No.No.
No.
ItemItem
ItemItem
Item
OrderOrder
OrderOrder
Order
DescriptionDescription
DescriptionDescription
Description
No.No.
No.No.
No.
No.No.
No.No.
No.
01-07061A
Rev. 01-08
1 644875 Mount – Drive Train
2 391467 Hydro Pump - Tandem (723T)
391470 Hydro Pump - Tandem (727T
6
)
3 130505 Filter
4 130431 Fan (723T)
130434 Fan (727T
6
)
5 130432 Retainer - Fan
6 253461 Nut – Nylon Insert
7 360061 Adapter Fitting 8MB-8MJ 90°
8 360064 Adapter Fitting 8MB-10MJ
9 424384 Hose Assembly .5 x 22
10 424385 Hose Assembly .5 x 23
11 424386 Hose Assembly .5 x 25
12 424070 Vibration Isolator – Flange
13 603611 Wheel Motor w/Hub (723T)
603614 Wheel Motor w/ Hub (727T
6
)
14 360063 Adapter Fitting 8MJ-10MB
15 243622 Sq Head Bolt .5-13 x 4
16 902299 Spacer – Wheel Motor
17 644862 Neutral Return Arm
18 603729 Roller Assembly – Eccentric
(includes items 19 & 20)
19 257410 External Star Washer
20 254450 Nut .375-16
21 257019 Washer .25 Hard
22 270832 Flange Bolt M6 x 1 x 40
23 253025 Whiz Nut .25-20
24 783730 Spacer – Neutral Return
25 253186 Whiz Bolt .312-24 x .75
26 265615 Ball Joint .312-24 RH Thread
27 265616 Ball Joint .312-24 LH Thread
28 780154 Rod – Steering Linkage 7.625
29 780156 Rod – Steering Linkage 13.0
30 254441 Nut .312-24 RH Thread
31 254444 Nut .312-24 LH Thread
32 253038 Whiz Nut .312-24
33 422039 Spacer – Return Plastic
34 775123 Spacer – Pump Mount
35 283823 Extension Spring
36 243030 Bolt .25-20 x 1.25
37 729542 Mount - Return
38 729639 Return Arm - Front
39 729398 Return Arm - Rear
40 424073 Vibration Isolator .375-16
41 725522 Front Mount – Tandem 700T
42 253192 Whiz Bolt .312-18 x .75
43 243215 Bolt .312-18 x 1.5
44 257030 Washer .312
45 243570 Bolt .5-13 x 1.5
46 257060 Washer .5
47 253066 Whiz Nut .5-13
48 774175 Washer – DD
49 388577 Coupler Hub – DD Bore
50 424150 Stabilizer - Coupling
51 253043 Whiz Nut .375-16
52 243206 Bolt .312-24 x 1
53 774176 Washer – 1 x 3
54 388560 Coupler Sleeve
55 281580 Sq. Key .25 x .690
56 388578 Coupler Hub 1"
57 774020 Washer - .406 x 1.25
58 243330 Bolt .375-16 x 1
59 253035 Whiz Nut .312-18
60 644094 Bracket – Expansion Tank
61 422033 Expansion Tank
62 365516 Plastic Plug - .375
63 423154 Tie .25 x 15
64 821709 Hydraulic Hose
65 280261 Clamp – Spring .312
66 821723 Vent Hose – Clear
67 722976 Shroud – Fan
68 722975 Shield – Coupler
69 130430 Fan Hub (723T)
130433 Fan Hub (727T
6
)
70 130510 Expansion Tank Adapter
71 243350 Bolt .375-16 x 2.25
72 257412 Lock Washer .375
73 243045 Bolt .25-20 x 2.25
74 257392 Lock Washer .25
75 822304 Pivot Bearing – Neutral Return
76 257044 Washer – Fender
77 243335 Bolt .375-16 x 1.25
78 253890 Lock Nut .375-16
79 274114 Whiz Nut M6 x 1
80 253203 Whiz Bolt .375-16 x 1
81 243475 Bolt .437-14 x 3
82 253465 Nut .437-14 Nylon Insert
83 902548 Spacer 1 x 2
84 424383 Hose Assembly .5 x 19.5
85 257025 Washer .257
86 253179 Whiz Bolt .25-20 x .75 Phil Truss
