Grasshopper 723T User Manual

42
TRACTION KIT
ItemItem
ItemItem
Item
OrderOrder
OrderOrder
Order
DescriptionDescription
DescriptionDescription
Description
No.No.
No.No.
No.
No.No.
No.No.
No.
ItemItem
ItemItem
Item
OrderOrder
OrderOrder
Order
DescriptionDescription
DescriptionDescription
Description
No.No.
No.No.
No.
No.No.
No.No.
No.
04061 / 07066
1 603699 Rocker w/Bearing Rt.
121764 Oilite Bearing
2 603700 Rocker w/Bearing Lt.
121764 Oilite Bearing
3 644635 Pin
4 604803 Spring Assembly - Offset
5 243395 Bolt .375-16 x 4.5 Full Thread
6 254450 Nut .375-16
7 247254 Carriage Bolt .375 x 1.375 Special
8 253890 Lock Nut .375-16
9 732410 Lift Strap
10 253192 Whiz Bolt .312-18 x .75
11 820320 Lift Chain (5 links)
12 253035 Whiz Nut .312-18
13 604708 Rocker Arm Extension Kit (opt.)
(includes 2 each of items 11 & 18-22)
14 260523 Hair Pin .094 x 2
15 257040 Washer .375
16 261362 Clevis Pin .375 x 1.75
17 262950 Push-on Retainer
18 261339 Clevis Pin .375 x .875 Sq. Shank
19 260648 Cotter Pin .125 x .5
20 644706 Extension - Rocker Arm
21 253203 Whiz Bolt .375-16 x 1
22 253043 Whiz Nut .375-16
23 820317 Lift Chain (3 Links)
21
22
19
18
11
20
21
19
22
18
20
11
1
2
3
3
12
10
7
4
8
9
9
18
23
19
5
6
7
8
9
9
12
18
23
19
07066
13
NOTE: Item 13 is not used with
33, 34, 96, 97 & 98 series decks;
use with all other decks and
attachments requiring traction
kit or hydraulic lift.
Not included with tractor assembly.
14
15
23
17
16
16
17
23
15
14
