14 / 44
16570.16572_Alpha150Q/170Q/220Q_V1
• Any alterations to the battery, charger or charging cables can
cause serious injury. Risk of fire and explosions! Risk of burns!
• Do not use any damaged battery or charger, risk of short-circuit
and fire!
Battery storage
LiPo batteries should be stored with a voltage of about 3,8V per cell.
If the cell voltage falls below 3 V, then the battery must be necessar-
ily charged. Deep discharge and storage in discharge status (cell volt-
age < 3V) make the battery useless. For transport and storage the
LiPo batteries should be placed in a safety bag e.g. No. 8373.
Notes
• Remove the battery from the model when transporting or when
not in use.
• During transport protect the model and the transmitter from
damages.
Charge the LiPo battery
Connect the LiPo battery to the supplied charger and charge it as
described in the corresponding manual.
First use
The following optional components may be required to commission
the copter:
Remote control HoTT transmitter (mz-12 Pro or higher) and a match-
ing charger.
For versions 16570.RTF, 16570.FPV and 16572.RTF and 16572.FPV,
optionally available video goggle (No. 48354) or an optionally avail-
able FPV monitor (No. S8405) are needed for the FPV flight.
Receiver
The integrated HoTT receiver is optimally matched to the respective
copter at the factory. To program some parameters, refer to the sec-
tion "Receiver settings".
Installing the LiPo battery in the copter
To compensate for the weight of the camera, place the LiPo battery
slightly backwards with a self-adhesive Velcro strip on the underside
