GRAUPNER Alpha 150Q User Manual

30 / 44
16570.16572_Alpha150Q/170Q/220Q_V1
Special functions on channel 6
Through the channel 6 of the transmitter it is possible to switch up
to three special functions, but the auto-flip function additionally
requires a mixer.
• Video channel switching
There are four video channels available in Europe. Between them
is switched in rotation process, each with a short control pulse of
+100% to the control channel 6. In parallel, the colour of the LED
lighting of the copters changes.
• red = Video channel R3
• green = Video channel R4
• blue = Video channel R5
• white = Video channel R6
To toggle the video channels as well as the lighting of the copter,
in the menu "Control setting", program one of the self-resetting
switches on your transmitter to "input 6" and leave the rest at
their default values.
In the preprogrammed model memory "Alpha 110" of the option-
ally supplied transmitter mz-12 Pro HoTT is the right front
mounted switch "S6". From this three-stage switch, only the
self-resetting switch function is used.
• Auto-Flip
With the auto-flip function, it is easy to perform a flip in the Atti-
tude mode with the copter.
However, since the auto-flip function should only be activated in
"Attitude mode", the corresponding dependency is established
by setting a free mixer of "5 => 6" as follows:
Programming step-by-step
1. Select "5" in the "from" column of a free linear mixer.
2. In the now accessible column "to",select "6" as target.
3. In the column above the switch symbol assign a self-resetting
switch, for example the switch 2 of the mz-12 Pro HoTT.
4. Change to the setting side of the mixer and hold down the
button just assigned to set the mixer.
5. According to the transmitter description, an asymmetrical
path of at least -110% has to be set. However, as shown in the
figure, a setting between -125% and -150% is recommended.
6. Recall the servo display for checking:
I5
I6
+
trv
3
SW6/7
+100%
+100%
+100%
+100%
I7 +100%
+100%
free
I8 +100%
+100%free
I9 +100%
+100%free
Typ
fro
zu
M1
M2
M3
S
6
??
??
M4
M5
??
??
??
??
??
??
2
–––
–––
–––
–––
L.MIX1
0%
0%
os
ASYSYM
5
trv
6
–125%
