SUMDI at channel X
SUMD SUMDI
S1019.AIR GR-18 HoTT (without vario) C6 ---
S1034 Falcon 12 plus C5 C6
S1035 Falcon 12 C5 C6
33579 GR-18 HoTT (with vario) C6 ---
33583 GR-24 Pro HoTT C8 C10
Receiver-specific input for a SUMD signal provided by almost all
HoTT receivers.
• "SERVO"
The receiver-specific connection is suitable for operating a servo
or comparable RC components.
• "SUMDI"
- If a receiver set to "SUMD" or “SUMD3” is connected to a
receiver set to "SUMDI" as described under "SUMD on chan-
nel X", a simple satellite connection is created with the
receiver set to SUMDI as the main receiver.
ശ If two suitable receivers are placed on SUMDI as well as on
SUMD and connected crosswise with two satellite cables, a
reciprocal satellite connection is created.
• “SBUSin” (only Falcon 12 and Falcon 12 plus)
- If a receiver set to “SBUS” or SBUS compatible receiver is con-
nected to a receiver set to “SBUSin” as described under “Kx:
SBUSin”, a simple satellite connection is created with the
receiver set to SBUSin as the main receiver.
ശ If two suitable receivers are placed on SBUSin as well as on
SBUS and connected crosswise with two satellite cables, a
reciprocal satellite connection is created.
Cx
Servo/Sensor/Voltage
S1019.AIR GR-18 HoTT (without
vario)
C9
S1034 Falcon 12 plus C5
S1035 Falcon 12 C5
33579 GR-18 HoTT (with vario) C9
33583 GR-24 Pro HoTT ---
• SERVO
The receiver-specific connection is suitable for operating a servo
or comparable RC components.
• SENSOR
