9
Transmission system SPCM und PPM (FM / FMsss)
Synthesizer RF section 35 MHz A-band and B-band
40/41 MHz band
Please refer to the table on page 13 for details of approved frequen-
cies in individual EU countries
Channel spacing, Synthesizer 10 kHz
Maximum control functions SPCM = 8, PPM = 8
Control functions 8 functions, 4 with trims
Channel pulse width 1,5 ms +/-0,5 ms
Temperature range -15 ... +55°C
Telescopic aerial 10-section, approx. 1150 mm long
Operating voltage 9,6 ... 12 V
Current drain approx. 225 mA (approx. 65 mA excl. RF)
Dimensions approx. 190 x 195 x 85 mm
Weight approx. 870 g incl. transmitter battery
Specifi cation of mx-16s transmitter
Accessories
Order No. Description
1121 Neckstrap, 20 mm wide
70 Neckstrap, 30 mm wide
3097 Wind-shield for hand-held transmitter
See page 111 for mx-16s Trainer leads
Replacement part
Order No. Description
3100.6 Telescopic aerial for mx-16s transmitter
Operating voltage 4,8 ... 6 V
Current drain approx. 24 mA
Spot frequencies, 35 MHz 61 ... 282 / 182 ... 191*
Spot frequ., 40 / 41 MHz 50 ... 92 / 400 ... 420**
Channel spacing 10 kHz
Sensitivity approx. 10 µV
Modulation PPM
Servo functions 8
Temperature range -15° ... +55° C
Aerial length approx. 1000 mm
Dimensions approx. 46 x 25 x 15 mm
Weight approx. 17 g
Specifi cation of R16SCAN receiver
The sets contain:
mx-16s transmitter with Synthesizer transmitter modu-
le on the appropriate frequency band, integral 8NH-1700
mAh NiMH battery (type may differ), R16SCAN receiver
on the appropriate frequency, one C 577 servo, switch
harness.
Order No. 4701 35 MHz band (A- and B-band)
Order No. 4703 40/41 MHz band
Please refer to the table on page 113 for details of approved frequen-
cies in individual EU countries.
Description of radio control system
* Channels 60, 281 and 282 not approved for use in Germany
** 41 MHz approved for use in France only
