DSCsocket
Connection socket for flight simulator or T/P systems
Trhough a DSC cable the port can serve to use the transmitter
with a simulator o to connect it with another one in Teacher/pupil
mode.
Switch the DSC mode in the "General settings menu". In this
way you can change the base display too. Right in the display
appears "DSC".
To ensure a correct DSC connection, observe the following:
1. Perform any necessary adaptations in the menu.
2. When using the transmitter with a flight simulator or during
the teacher-pupil operation, set the On/Off switch always on
the "Off" position. Connect one end of the DSC cable in the DSC
port of the transmitter.
3. Switch the transmitter on.
ATTENTION!
When your transmitter is directly connected to a desktop computer
by a connecting cable (DSC cable) and/or a computer interface is
connected to your simulator, the transmitter may be destroyed
byelectrostatic discharge. This type of connection should therefore
only be used if you protect yourself from electrostatic discharge
while operating the simulator by wearing a commercially available
grounding armband. Graupner therefore strongly recommends only
using wireless simulators.
