22 / 28
S1005_S1006_jp_V1
2. Through charge socket and charge with AC charger
CAUTION
Do not use plug-in chargers by other manufacturers or chargers that
were designed for different battery types. Transmitter and battery
can be damaged. Risk of fire!
Make sure that the transmitter is switched off. The transmitter
must be turned offwhile the entire charging process.
Connect the jack of the included AC charger to the charge
socket.
A completely discharged battery requires approx. 15 hours to
be charged.
Polarity of the mz charging socket
The charging cables available on the market by other manufac-
turers frequently have different polarities. For this reason, you
should only use original Graupner charging cable.
NOTE
The charging socket comes standard with a protection switch that
protects against polarity reversal. Original Graupner automatic char-
gers recognize the battery charge. In order to prevent damage to the
protection switch and to the other components, charging current
should never exceed 1 A.
Battery use timer in the display
The use timer is shown in the lower left part of the display in
green.
The battery use time is added at every use. Every time that the
voltage is higher than the use before the timer is reset to
"00:00:00". This happens only if the voltage is at least 0,3V
higher then before, it means it happens through a battery charge.
