20 / 28
S1005_S1006_jp_V1
tors and reverse polarity protection. Make sure that the
polarity is correct.
After the charge is complete disconnect the charger from the
power source.
The battery charger can be used only in dry spaces.
A wet charger, even if re-dried, should no longer be used.
Never use a damaged battery charger.
Due to licensing reasons, any reconstruction and/or modifi-
cation of the product is prohibited.
Be sure that during charge the charger is not covered. The
ventilation slots must be free.
Removing transmitter battery
Remove the battery case cover.
Then remove and disconnect the battery plug.
Lift the battery and pull it away from the Velcro tape.
Inserting the transmitter battery
The battery connection is protected by two beveled edges from
polarity reversalwhen plugging in.
Plug the battery connector carefully and pay attention to the cor-
rect polarity.
Charge possibilities
CAUTION
The transmitter must be turned offwhile the entire charging process.
You have two charge possibilities:
1. By removing the battery from its case and charging it with a
charger
Removing transmitter battery
Remove the battery case cover.
Then remove and disconnect the battery plug.
Lift the battery and pull it away from the Velcro tape.
Charge the battery following the charger manual.
