9
5. Installation
5.1 Installation location
Monitor installation location
Standard monitor installation height is about
1,500mm where screen center is at eye level; in
this case, wall-hanging metal center is 1,450mm
above ground level.
5.2 Wire & Monitor Installation
1) Push down the button with screwdriver
2) Put the wire into the hole from the bottom
3) Release the screwdriver
4) Check the fastness of the wire
5) Remove wall-hanger bracket behind monitor
6) Install wall-hanger bracket
7) Connect wires to back terminal of monitor,
referring to connection diagram
8) Hang monitor on wall-hanging, and fix
monitor on wall-hanger bracket
9) Plug monitor’s power plug into power socket
