24
¾ Set ring timeout:10 s/20 s/30 s.
In [Factory Reset] setting page you can restore system to factory settings (except date
& time, intercom address).
7. Specifications
Category Specification
Input power
AC: 100V ~ 240V, 50Hz/60Hz
DC: 14.5V
Power Consumption Max: 12W, standby: 5W
TFT LCD 7 inch digital TFT LCD
LCD resolution 800(RGB) x 480
Connection with door station Support two 4-wire door stations
Connection with CCTV Support four 2-wire CCTV input
Connection with extension monitor Support three extension monitors
Connection with audio phone Support one 4-wire audio phone
Connection with video out Support one 2-wire video out
Memory capacity
TF card: 1024 pictures, 128 videos
Flash: 100 pictures
Dimensions (mm) 238mm (W) * 157mm(H) * 28.5mm(D)
