HackRF
Pin Function
1 CLKOUT
2 CLKIN
3 RESET
4 GND
5 I2C1_SCL
6 I2C1_SDA
7 SPIFI_MISO
8 SPIFI_SCK
9 SPIFI_MOSI
10 GND
11 VCC
12 I2S0_RX_SCK
13 I2S_RX_SDA
14 I2S0_RX_MCLK
15 I2S0_RX_WS
16 I2S0_TX_SCK
17 I2S0_TX_MCLK
18 GND
19 U0_RXD
20 U0_TXD
21 P2_9
22 P2_13
23 P2_8
24 SDA
25 CLK6
26 SCL
4.10.4 P28 SD
SDIO, GPIO, clocks, and CPLD.
14 Chapter 4. HackRF One
