HackRF
Pin Function
1 VCC
2 GND
3 SD_CD
4 SD_DAT3
5 SD_DAT2
6 SD_DAT1
7 SD_DAT0
8 SD_VOLT0
9 SD_CMD
10 SD_POW
11 SD_CLK
12 GND
13 GCK2
14 GCK1
15 B1AUX14
16 B1AUX13
17 CPLD_TCK
18 BANK2F3M2
19 CPLD_TDI
20 BANK2F3M6
21 BANK2F3M12
22 BANK2F3M4
Additional unpopulated headers and test points are available for test and development, but they may be incompatible
with some enclosure or expansion options.
Refer to the schematics and component documentation for more information.
