Gree FP-85XD/B-T Service Manual

PRODUCT
10
Notes:
(a) The water working temperature is from 7°C(44.6°F) to 60°C(140°F).
(b) The temperature exchange efficiency and enthalpy exchange efficiency are tested under these
testing conditions as below:
 Cooling efficiency: air 27°C(80.6°F) DB, 19.5°C(67.1°F) WB, water temperature in
7°C(44.6°F),water out 12°C(53.6°F).
 Heating capacity: air 21°C(69.8°F) DB, Water temperature intake 60°C(140°F), the water-flow
volume is same as Cooling capacity.
Model
FP-51XD/A-K
FP-68XD/A-K
Code
EM520N1170
EM520N1160
Power system
Type
V-Ph-Hz
220-240V~ 50Hz
220-240V~ 50Hz
Input
W
73
73
Air flow volume
High
CFM
300
400
m
3
/h
510
680
Medium
CFM
235
329
m
3
/h
400
560
Low
CFM
176
270
m
3
/h
300
460
Capacity
Cooling
W
2750
3600
Heating
W
3400
4200
Electric heater rated power
W
-
-
Water system
Cooling water flow volume
l/s
0.13
0.18
Heating water flow volume
l/s
0.16
0.20
Cooling pressure drop
kPa
15
28
Heating pressure drop
kPa
24
38
Sound pressure level
dB(A)
46
46
Coil
Type
-
Aluminum fin-copper tube
Aluminum fin-copper tube
Operating pressure
MPa
≤1.6MPa
≤1.6MPa
Motor
Type
-
FN30L
FN30L
Capacitor
µF
2
2
Connection pipe
size
Water inlet &outlet
inch
G3/4
G3/4
Condensing water drain
mm
25
25
Outline dimension
Body
mm
664x594x292
664x594x292
