PRODUCT
11
(W×H)
Panel TC06
mm
670x670x60
670x670x60
Package
dimension
(W×H)
Body
mm
775x730x285
775x730x285
Panel TC06
mm
760x760x90
760x760x90
Net weight
Body
kg
20
20
Panel TC06
kg
3.5
3.5
Gross weight
Body
kg
24
24
Panel TB03
kg
5
5
20'GP (with panel TB03)
168
168
40'GP (with panel TB03)
376
376
40'HQ (with panel TB03)
423
423
Wired remote controller
Z4E351B
Z4E351B
Wireless remote controller
YB1FA(MOTO)
YB1FA(MOTO)
Notes:
Testing condition:
The FCU designed for installation indoor. The environmental temperature is fromC to 43°C, water
working temperature is from 7°C to 60°C.
The temperature exchange efficiency and enthalpy exchange efficiency are tested under these testing
conditions as below:
(a) Cooling capacity: air 27°C DB , 19°C WB, water temperature intake 7°C, outlet 12°C.
(b) Heating capacity: air 20°C DB , Water temperature intake 45°C, outlet 40°C.
(c) Freeze-up : air 27°C DB, 24°C WB , water temperature C intake , 10°C outlet .
(d) Sound power level according to ISO 5151. Sound pressure level are calculated at the below of
air-outlet 1m and 1m distance. The noise are tested before leaving factory.
