Gree GMV-N22G/A3A-K

GREE GMV5 INDOOR UNIT SERVICE MANUAL
202
No.
Name of part
For the following unit
For the following unit
Unit
Product Code
Unit
Product Code
GMV-ND90PLS/A-T
CM800N3450
GMV-ND125PLS/A-T
CM800N3480
GMV-ND100PLS/A-T
CM800N3460
GMV-ND140PLS/A-T
CM800N3470
GMV-ND112PLS/A-T
CM800N3530
/
/
Part code
Quantity
Part code
Quantity
12
Bottom Cover Plate
01265343
1
01265343
1
13
Electric Box Assy
01394100242
1
01394100242
1
14
Filter Board
30226000051
2
30226000051
2
15
Main Board
30226000030
1
30226000030
1
16
Terminal Board
42011106
1
42011106
1
17
Terminal Board
4201800002601
1
4201800002601
1
18
Right Side Plate Assy
01314100055
1
01314100055
1
19
Electric Box Cover
01425262
1
01425262
1
20
Seal Of Connection Pipe sub-assy
01495238
1
01495238
1
21
Left Baffler Sub-Assy
12505217
1
12505217
1
22
Water Pump
4313822001
1
4313822001
1
23
Water Level Switch
5020216
1
45020216
1
24
Electronic Expansion Valve
07334468
1
07334468
1
25
Strainer
0741410000601
1
0741410000601
1
26
Filter Sub-Assy
07210028
1
07210028
1
27
Border Plate of Air outlet Sub-Assy
02225270
1
02225270
1
28
Filter
07415210
1
07415210
1
29
Evaporator Assy
01024100106
1
01024100107
1
30
Water Tray Assy
01285275
1
01285275
1
31
Top Cover Board Assy
0126534901
1
0126534901
1
32
Choke Plug of Drain Pipe
76815214
2
76815214
2
33
Right Baffler Sub-Assy
12505216
1
12505216
1
34
Left Side Plate Assy
01315299
1
01315299
1
35
Hook
02112466
4
02112466
4
36
Drain Hose Sub-Assy
05232050
1
05232050
1
37
Sensor Sub-assy
39004169G
1
39004169G
1
38
Display Board
30296000040
1
30296000040
1
39
Pump Drainpipe
04615487
1
04615487
1
40
Corrugated Pipe
05015408
1
05015408
1
41
Electric Expand Valve Fitting
4304413215
1
4304413215
1
Above data is subject to change without notice, pls reference the SP in global service website.
