GREE GMV5 INDOOR UNIT SERVICE MANUAL
212
NO
Model
GMV-ND22T/B-T
GMV-ND28T/B-T
GMV-ND36T/B-T
GMV-ND45T/B-T
GMV-ND50T/B-T
GMV-ND56T/B-T
Qty
Product Code
CM500N0610
CM500N0620
CM500N0630
CM500N0640
CM500N0600
CM500N0650
Part Name
Part Code
1
Base Plate Assy
02229400007
1
2
Evaporator Assy
01024100137
1
3
Water Tray Assy
01289400004
1
4
Liquid Level Switch
450102013
1
5
Water Pump
43138000024
1
6
Right Side Plate Sub-Assy
01319400013
2
7
Brushless DC Motor
15709400004
1
8
Rear Grill
26909400007
1
9
Diversion Circle
10479400001
1
10
Front Side Plate Sub-Assy
01319400014
1
11
Main Board
30226000029
1
12
Transformer
43118000015
1
13
Terminal Board
42011106
1
14
Terminal Board
4201800002601
1
15
Electric Box Assy
01394100456
1
16
Electric Box Cover
01429400003
1
17
Left Side Plate Sub-Assy
01319400012
1
18
Centrifugal Fan
10429400001
1
19
Remote Controller
30510589
1
20
Drain Hose Sub-Assy
05232050
1
21
Strainer
0741410000601
2
22
Electronic Expansion Valve
07334463
1
23
Electric Expand Valve Fitting
4304413215
1
Above data is subject to change without notice, pls reference the SP in global service website.
