Gree GMV-N22G/A3A-K

GREE GMV5 INDOOR UNIT SERVICE MANUAL
244
NO.
Model
GMV-NX224P/A(X2.0)-M
Qty.
Product Code
CM800N3620
Part Name
Part Code
12
Choke Plug
76718209
8
13
Main water Tray
26902206
1
14
Filter Sub-Assy
11722202
1
15
Motor for Centrifugal Fan
1570220201
1
16
Fan Motor
15702237
1
17
Right Side Plate Sub-Assy
01312200026
1
18
Rear Side Plate Sub-Assy
01312200028
1
19
Blower Mounting Plate
01322200010
1
20
Electric cabinet board
01394100522
1
21
Capacitor CBB65
3300008111
1
22
Terminal Board
4201115404
1
23
Main Board
30226000004
1
24
Terminal Board
4201800002601
1
25
Top Cover Plate Sub-Assy
01262200028
1
26
Left Side Plate Sub-Assy
01312200030
1
27
Sensor Sub-assy
39008000103G
1
28
Display Board
30296000040
1
GMV-NR71A/A-D
NO.
Model
GMV-NX224P/A(X2.0)-M
Qty.
Product Code
CM800N3620
Part Name
Part Code
1
insulating board
75142201
1
2
Lower cover plate 1
01264100070
1
3
Top Cover Board Sub-assy
01262200007
1
4
Plastic Cover
26902209
4
5
Lower cover plate sub-assy 2
01262200009
1
6
Evaporator Assy
01024100162
1
7
Current Divider
072241303
1
8
Strainer
0721200101
2
9
Electronic Expansion Valve
07334466
1
10
Electric Expand Valve Fitting
4304413205
1
11
Secondary Water Tray
26902200002
1
12
Choke Plug
76718209
8
13
Main water Tray
26902200001
1
14
Filter Sub-Assy
1172220202
1
15
Motor for Centrifugal Fan
1570220101
1
16
Fan Motor
1570221401
1
17
Right Side Plate Sub-Assy
01312200007
1
18
Rear Side Plate Sub-Assy
01312200009
1
19
Blower Mounting Plate
01322200008
1
20
Electric cabinet board
01394100523
1
21
Capacitor CBB65
33000074
1
22
Terminal Board
4201115404
1
23
Main Board
30226000004
1
24
Terminal Board
4201800002601
1
25
Top Cover Plate Sub-Assy
01262200010
1
