GREE GMV5 INDOOR UNIT SERVICE MANUAL
254
No.
Name of part
For the following unit
Unit
Product Code
GMV-ND22PHS/B-T
CM810N0300
GMV-ND25PHS/B-T
CM810N0310
GMV-ND28PHS/B-T
CM810N0320
GMV-ND32PHS/B-T
CM810N0330
GMV-ND36PHS/B-T
CM810N0340
Part code
Quantity
1
Display Board
30296000040
1
2
Drain Hose Sub-Assy
05232050
1
3
Temperature Sensor
390000454
1
4
Temperature Sensor
390000592
1
5
Temperature Sensor
3900005910
1
6
Right Side Plate Assy
01315200148
1
7
Hook
02112466
4
8
Centrifugal Fan Assy
15404100074
1
9
Propeller Housing(Upper)
26905200078
1
10
Return Air Frame Sub-Assy
017026000004
1
11
Centrifugal Fan
10455200003
1
12
Supporter(Fan motor)
0180520027201
1
13
Brushless DC Motor
1570520000501
1
14
Propeller Housing(Lower)
26905200079
1
15
Filter Sub-Assy
111001000055
1
16
Foam Sub-assy
12505200038
1
17
Cover Of Air-In
01265200182
1
18
Bottom Cover Plate
01265200181
1
19
Left Side Plate Assy
01315200147
1
20
Inductance
43128000014
1
21
Terminal Board
4201115402
1
22
Terminal Board
4201800002601
1
23
Main Board
30226000089
1
24
Electric Box Assy
100002000985
1
25
Choke Plug Of Drain Pipe
76815214
2
26
Seal Plate Assy
01495200079
1
27
Water Pump
43138000058
1
28
Water Level Switch
45020216
1
29
Electric Expand Valve Fitting
4304413215
1
30
Strainer
07415210
1
31
Strainer
0741410000601
1
32
Electronic Expansion Valve
07334466
1
33
Evaporator Assy
011001000296
01024100171
1
34
Air Outlet Frame Assy
01374100070
1
35
Top Cover Board Assy
01264100081
1
Above data is subject to change without notice, pls refer the SP in global service website.
