Gree GMV-N22G/A3A-K

GREE GMV5 INDOOR UNIT SERVICE MANUAL
260
No.
Name of part
For the following unit
Unit
Product Code
GMV-ND90PHS/B-T
CM810N0420
GMV-ND100PHS/B-T
CM810N0430
GMV-ND112PHS/B-T
CM810N0440
GMV-ND125PHS/B-T
CM810N0450
Part code
Quantity
12
Bottom Cover Plate
01265200125
1
13
Left Side Plate Assy
01315200147
1
14
Hook
02112466
4
15
Water Level Switch
45020216
1
16
Water Pump
43138000058
1
17
Seal Plate
01495200078
1
18
Reactor
43138000047
1
19
Terminal board
4201115402
1
20
Terminal Board
4201800002601
1
21
Main Board
300002000009
1
22
Electric Box Assy
100002000984
1
23
Air Outlet Frame Assy
01375200023
1
24
Evaporator Assy
011001000070
1
25
Electric Expand Valve Fitting
4304413215
1
26
Strainer
0741410000601
1
27
Electronic Expansion Valve
07334468
1
28
Strainer
07415210
1
29
Foam Sub-Assy
12505200021
1
30
Top Cover Board Assy
01264100105
1
31
Right Side Plate Assy
01315200148
1
32
Display Board
30296000040
1
33
Temperature Sensor
3900005910
1
34
Temperature Sensor
390000592
1
35
Temperature Sensor
390000454
1
36
Drain Hose Sub-Assy
05232050
1
37
Corrugated Pipe
05015408
1
Above data is subject to change without notice, pls refer the SP in global service website.
