GREE Photovoltaic Direct-driven Inverter Multi VRF Units
120
2.3.2.4 Communication System Check
1) The following communication contents must be checked again before commissioning:
Do main boards correctly communicate with each other
between outdoor unit modules?
Are DIP switches of the master outdoor unit correctly set?
Are indoor units correctly connected with each other?
Does the master outdoor unit correctly communicate
with the indoor unit?
Does the indoor unit correctly communicate with the
wired controller?
2) Communication cables cannot be laid out in the same trough as power cables. Communication
cables should be independently laid out in hard fire-resistant PVC tubes. The parallel spacing
between communication cables and strong electric wires should be larger than 20 cm.
2.3.2.5 Installation and Master of Commissioning Software
2.3.2.6 Spot Check
Spot Check for Commissioning
Is the engineering design diagram complete?
Does the construction comply with the design diagram?
3 Is the rated capacity of the IDU/ODU of a single refrigerating system within 50%-135%?
Is the number of connected IDUs in a single refrigerating system within 80?
Is the access capacity of a fresh-air unit within 30%?
Does the difference of level between IDUs and ODUs comply with unit design requirements?
Does the difference of level between IDUs comply with unit design requirements?
Are long pipes of IDUs and ODUs less than or equal to 165 m(541ft)?
Is the total length of pipes less than 1000 m(3280ft)?
11
Is the spacing between the ODU and the first disperse pipe larger than 90 m(295ft)? If yes, is the
corresponding pipe diameter increased?
12
Is the spacing between the IDU and the nearest disperse pipe larger than 10 m(33ft)? If yes, is the
corresponding pipe diameter increased?
Does the wall thickness of copper tubes meet design requirements?
Are disperse pipes horizontal or vertical?
Does the diameter of cables connected with IDUs and ODUs comply with unit design requirements?
