GREE Photovoltaic Direct-driven Inverter Multi VRF Units
13
4.2 Basic Parameter of Photovoltaic Parts and Components
4.2.1 Photovoltaic modules
Type of battery
Monocristalline PV
module
Monocristalline PV module
Monocristalline PV
module
Quantity of battery
60
60
60
Peak power (Wp)
285
290
295
Peak voltage (V)
31.47
31.66
31.86
Peak current (A)
9.06
9.16
9.26
Open-circuit voltage (V)
38.23
38.45
38.67
Short-circuit current (A)
9.50 9.61 9.72
Efficiency of component (%)
17.33 17.64 17.94
Temperature coefficient of peak power
(%/℃)
-0.410
Temperature coefficient of open-circuit
voltage (%/℃)
-0.330
Temperature coefficient of short-circuit
current (%/
℃
)
0.059
Temperature coefficient of peak power and
voltage (%/℃)
-0.323
Dimension (mm)
1658×992×22
Weight (kg)
23.3
4.2.2 Current converting unit
G-IEMS
Intelligent Converter
GIE-ADC12K5E
Max. PV Input Voltage(OC)
1000VDC
Isc PV
39A
Max. continuous input current
2*14A
Max. PV Input Power
14kW
MPPT Range
400V—780V
Max. DC continuous output current
25A
Rated DC output Current
25A
DC output Voltage
400V—780V
Rated AC Voltage
208 / 240Vac 3~ + PE
Rated Frequency
60Hz
Rated AC Power
12.5kW
Rated AC Current
35A*3 / 30A*3
Power factor
-0.8~0.8
Ambient Temperature
-20℃—50℃
Ingress Protection
TYPE 3
Certifications
UL 1741
IEEE 1547
Note: The product can work in different modes by configuring Grid voltage.
Manufacturer: GREE Energetic & Environmental Technologies Co., Ltd. of
Zhuhai
Made in China
