Gree GMV5 Service Manual

GREE Photovoltaic Direct-driven Inverter Multi VRF Units
12
Outdoor Units_Heat
Pump
－
24Ton 26Ton 28Ton 30Ton
Model
－
GMV
-Y288WM/C-F(U) GMV-Y312WM/C-
F(U)
GMV-Y336WM/C-
F(U)
GMV-Y360WM/C-F(U)
Module (combinated)
－
GMV-Y96WM/C-F(U)
+ GMV-Y96WM/C-F(U)
+GMV-Y96WM/C-F(U)
GMV-Y96WM/C-F(U)
+GMV-Y96WM/C-F(U)
+GMV-Y120WM/C-F(U)
GMV-Y96WM/C-F(U)
+GMV-Y120WM/C-F(U)
+GMV-Y120WM/C-F(U)
GMV-Y120WM/C-F(U)
+GMV-Y120WM/C-F(U)
+GMV-Y120WM/C-F(U)
Cooling capacity Btu/h 288000 312000 336000 360000
Heating capacity Btu/h 324000 351000 378000 405000
Air volume CFM 8240+8240+8240 8240+8240+8240 8240+8240+8240 8240+8240+8240
Max. external static
pressure
Pa 82 82 82 82
Power
－
208/240V 3~ 60Hz 208/240V 3~ 60Hz 208/240V 3~ 60Hz 208/240V 3~ 60Hz
Input power for cooling kW 7.30+7.30+7.30 7.30+7.30+10.00 7.30+10.00+10.00 10.00+10.00+10.00
Input power for heating kW 7.85+7.85+7.85 7.85+7.85+10.50 7.85+10.50+10.50 10.50+10.50+10.50
Input current for
cooling
A 20.37+20.37+20.37 20.37+20.37+26.27 20.37+26.27+26.27 26.27+26.27+26.27
Input current for heating
A 23.50+23.50+23.50 23.50+23.50+27.87 23.50+27.87+27.87 27.87+27.87+27.87
MOP A
208V:45+45+45
240V:40+40+40
208V:45+45+45
240V:40+40+40
208V:45+45+45
240V:40+40+40
208V:45+45+45
240V:40+40+40
MCA A
208V:43.6+43.6+43.6
240V:37.3+37.3+37.3
208V:43.6+43.6+44.8
240V:37.3+37.3+39.8
208V:43.6+44.8+44.8
240V:37.3+39.8+39.8
208V:44.8+44.8+44.8
240V:39.8+39.8+39.8
Refrigeration oil no. of
compressor
－
FVC68D or FV68H FVC68D or FV68H FVC68D or FV68H FVC68D or FV68H
Ambient temperature
range for cooling
℉
23~125.6 23~125.6 23~125.6 23~125.6
Ambient temperature
range of heating
℉
-4~75.2 -4~75.2 -4~75.2 -4~75.2
Refrigerant type
－
R410A R410A R410A R410A
Charging volume of
refrigerant
oz 398.6+398.6+398.6 398.6+398.6+416.2 398.6+416.2+416.2 416.2+416.2+416.2
Max. quantity of
connected indoor unit
unit 50 53 56 59
Size of gas pipe in. Φ1-3/8 Φ1-3/8 Φ1-3/8 Φ1-5/8
Size of liquid pipe in. Φ3/4 Φ3/4 Φ3/4 Φ3/4
Size of oil
-
balanced pipe
in. Φ3/8 Φ3/8 Φ3/8 Φ3/8
Outline
dimension(WxDxH)
in.
(52-3/4x30-1/8x63-1/4)
x3
(52-3/4x30-1/8x63-1/4)
x3
(52-3/4x30-1/8x63-1/4)
x3
(52-3/4x30-1/8x63-1/4)
x3
Packing size(WxDxH) in. / / / /
Net weight LBS 650+650+650 650+650+650 650+650+650 650+650+650
Gross weight LBS 683+683+683 683+683+683 683+683+683 683+683+683
No matter how many outdoor units there are, the total rated capacity of indoor units must not
exceed 135% of the total rated capacity of outdoor units. Stable and safe operation can only be
guaranteed in a range of 50%~135%.
