Gree GMV5 Service Manual

GREE Photovoltaic Direct-driven Inverter Multi VRF Units
11
Outdoor Units_Heat Pump
－
18Ton 20Ton 22Ton
Model
－
GMV-Y216WM/C-F(U) GMV-Y240WM/C-F(U) GMV-Y264WM/C-F(U)
Module (combinated)
－
GMV-Y96WM/C-
F(U)+
GMV-Y120WM/C-F(U)
GMV-Y120WM/C-
F(U)+
GMV-Y120WM/C-F(U)
GMV-Y72WM/C-
F(U)+
GMV-Y96WM/C-
F(U)+
GMV-Y96WM/C-F(U)
Cooling capacity Btu/h 216000 240000 264000
Heating capacity Btu/h 243000 270000 297000
Air volume CFM 8240+8240 8240+8240 6710+8240+8240
Max. external static pressure Pa 82 82 82
Power
－
208/240V 3~ 60Hz 208/240V 3~ 60Hz 208/240V 3~ 60Hz
Input power for cooling kW
7.30+10.00 10.00+10.00 5.45+7.30+7.30
Input power for heating kW
7.85+10.50 10.50+10.50 5.80+7.85+7.85
Input current for cooling A
20.37+26.27 26.27+26.27 16.42+20.37+20.37
Input current for heating A
23.50+27.87 27.87+27.87 17.29+23.50+23.50
MOP A
208V:45+45
240V:40+40
208V:45+45
240V:40+40
208V:45+45+45
240V;40+40+40
MCA A
208V:43.6+44.8
240V:37.3+39.8
208V:44.8+44.8
240V:39.8+39.8
208V:35.3+43.6+43.6
240V:30.3+37.3+37.3
Refrigeration oil no. of
compressor
－
FVC68D or FV68H FVC68D or FV68H FVC68D or FV68H
Ambient temperature range
for cooling
℉
23~125.6 23~125.6 23~125.6
Ambient temperature range of
heating
℉
-4~75.2 -4~75.2 -4~75.2
Refrigerant type
－
R410A R410A R410A
Charging volume of
refrigerant
oz 398.6+416.2 416.2+416.2 229.3+398.6+398.6
Max. quantity of connected
indoor unit
unit 36 39 46
Size of gas pipe in. Φ1-1/8 Φ1-3/8 Φ1-3/8
Size of liquid pipe in. Φ5/8 Φ5/8 Φ3/4
Size of oil-balanced pipe in. Φ3/8 Φ3/8 Φ3/8
Outline dimension(WxDxH) in.
(52-3/4x30-1/8x63-1/4)
x2
(52-3/4x30-1/8x63-1/4)
x2
(36-5/8x30-1/8x63-1/4)
+(52-3/4x30-1/8x63-1/4)x2
Net weight
(Not include converter)
LBS 650+650 650+650 487+650+650
Gross weight
(Not include converter)
LBS 683+683 683+683 514+683+683
