Gree GMV5 Service Manual

GREE Photovoltaic Direct-driven Inverter Multi VRF Units
87
(2) ∑Refrigerant charging amount B of every module.
Refrigerant charging amount B of every module
kg(Pounds)
Rated Capacity(1000Btu/h)
IDU/ODU rated capacity
collocation ratio C
Quantity of
included IDUs(N)
72 96 120
50%≤C≤90%
N<4 0 0 0
N≥4 0.5(1.1) 0.5(1.1) 0.5(1.1)
90%<C≤105%
N<4 1(2.2) 1(2.2) 1.5(3.3)
8>N≥4 2(4.4) 2(4.4) 3(6.6)
N≥8 4(8.8) 3.5(7.7) 4(8.8)
105%<C≤135%
N<4 2(4.4) 2(4.4) 2.5(5.5)
8>N≥4 4(8.8) 3.5(7.7) 4(8.8)
N≥8 4.5(9.9) 4.5(9.9) 5(11.0)
(1) IDU/ODU rated capacity collocation ratio C = Sum of rated cooling capacity of indoor unit / Sum of rated
cooling capacity of outdoor unit.
(2) If all of the indoor units are fresh air indoor units, the quantity of refrigerant added to each module is 0kg.
(3) If outdoor air processor is connected with normal VRF indoor unit, adopt the perfusion method for normal
indoor unit for perfusion.
For example1:
The ODU is composed of 3 modules: 72kBtu/h, 120 kBtu/h and 120 kBtu/h. The IDUs are made up
of 7sets of 48 kBtu/h.
IDU/ODU rated capacity collocation ratio C= 48×7/(72+120+120)=108%.The quantity of included
IDUs is more than 4 sets. Please refer to the above table.
Refrigerant charging amount B for 72kBtu/h module is 4.0kg(8.8pounds).
Refrigerant charging amount B for 120 kBtu/h module is 4.0kg(8.8pounds).
Refrigerant charging amount B for 120 kBtu/h module is 4.0kg(8.8pounds).
So, Σ Refrigerant charging amount B of every module=4.0+4.0+4.0=12kg (8.8+8.8+8.8
=26.4pounds).
Suppose the Pipeline charging amount A=Σ Liquid pipe length × refrigerant charging amount of
every 1m (or 1in.) liquid pipe=25kg (55.1 pounds)
Total refrigerant charging amount R=25+12=37kg (55.1+26.4=81.5pounds).
For example 2:
Outdoor unit is a 72kBtu/h module and the indoor unit is a 72kBtu/h fresh air unit. The quantity (B) of
refrigerant added to this module is 0kg (0pounds).
So, ΣB (Quantity of refrigerant added to each module) = 0kg (0pounds).
Suppose that A (Quantity of refrigerant added to connection pipe) = ∑ Length of liquid pipe x
Quantity of refrigerant added to liquid pipe per meter) = 5kg (11pounds).
R (Quantity of added refrigerant in total) = 5+0=5kg (11+0=11pounds).
Modular combination of outdoor unit subjects to combinations that is currently available.
