4.2 Product Data of Indoor Unit
4.2.1 Wall mounted type
Hansol
Model
GWH09TB-D3
DNA1A/I
GWH12TB-D3
DNA1A/I
GWH18TC-D3
DNA1A/I
GWH24TD-D3
DNA1A/I
Capacity
Cooling kW 2.6 3.5 5.3 7.1
Heating kW 2.87 3.8 5.6 7.3
Power supply V-Ph-Hz 208/230-1-60 208/230-1-60 208/230-1-60 208/230-1-60
Motor power input kW 0.029 0.029 0.045 0.070
Air flow volume
m3/h 730 770 1000 1100
CFM 430 453 588 647
Sound pressure level
(SH/H/MH/M/ML/L/SL)
dB(A)
42/36/34/32/28/
24/21
43/36/34/32/28/
24/22
51/48/45/43/39/
36/33
52/49/46/44/42/
40/37
Fan motor
Output kW 0.010 0.010 0.025 0.045
Running
current
A 0.07 0.07 0.1 0.3
Connecting
pipe
Gas inch 1/2″(Φ12.7mm) 1/2″(Φ12.7mm) 5/8″(Φ15.9mm) 5/8″(Φ15.9mm)
Liquid inch 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 1/4″(Φ6.35mm)
Connection method
Flare
Connection
Flare
Connection
Flare
Connection
Flare
Connection
Drain pipe
External dia. mm Φ20 Φ20 Φ20 Φ20
Thickness mm 1.5 1.5 1.5 1.5
Outline
dimension
W×D×H mm 866×209×292 866×209×292 1018×230×319 1178×264×326
Package
dimension
W×D×H mm 945×297×377 945×297×377 1097×340×397 1256×364×414
Net Weight/Gross weight kg 11.0/14.0 11.0/14.0 14.0/19.0 18.0/22.0
Loading quantity
20'GP 288 288 199 126
40' GP 590 590 402 276
40' HQ 668 668 458 322
Notes:
a. Refer to the product nameplate for parameters and specification of the unit;
b. The data will change with the change of products. Refer to those parameters listed on nameplate.
c. Noise was tested in semi-silenced room, so the actual noise value will be a little higher for change of ambient.
