Service Manual
MAINTENANCE
N
159
7.2 Indoor unit
7.2.1 Wall mounted type
◆ Hansol
GWH09TB-D3DNA1A/I; GWH12TB-D3DNA1A/I; GWH18TC-D3DNA1A/I
Part list:
GWH09TB-D3DNA1A/I for CB148N02200; GWH12TB-D3DNA1A/I for CB148N02300;
GWH18TC-D3DNA1A/I for CB148N04000;
NO. Description
GWH09TB-D3DNA1A/I GWH12TB-D3DNA1A/I GWH18TC-D3DNA1A/I
Code Qty Code Qty Code Qty
1 Front Panel 20012850K 1 20012850K 1 20012820U 1
2 Display Board 30565140 1 30565140 1 30565141 1
3 Filter Sub-Assy 1112211602 2 1112211602 2 1112209105 2
4 Front Case Sub-assy 2001288902 1 2001288902 1 20012821 1
5 Guide Louver 10512267 1 10512267 1 10512283 1
