Super Free Match
Service Manual
MAINTENANCE
160
6 Guide Louver (small) 10512127 1 10512127 1 1051222601 1
7 Crank 10582070 2 10582070 2 10582070 2
8
Helicoid Tongue
sub-assy
2611224404 1 2611224404 1 2611236701 1
9 Left Axile Bush 10512037 2 10512037 2 1051203701 2
10 Propeller Axile Bush 1054202101 1 1054202101 1 1054204701 1
11 Evaporator Support 24212114 1 24212114 1 24212139 1
12 Evaporator Assy 01002364 1 01002364 1 0100238601 1
13 Cross Flow Fan 10352033 1 10352033 1 10352045 1
14 Drainage Hose 05230014 1 05230014 1 0523001406 1
15 Fan Motor 15013314 1 15013314 1 15012127 1
16 Wall Mounting Frame 01252484 1 01252484 1 01252123 1
17 Motor Press Plate 26112209 1 26112209 1 26112330 1
18
Rubber Plug (Water
Tray)
76712012 1 76712012 1 76712012 1
19 Pipe Clamp 2611216402 1 2611216402 1 26112188 1
20 Rear Case assy 2220216103 1 2220216103 1 22202499 1
21 Axile Bush 10542036 3 10542036 3 10542036 4
22 Step Motor 15212123 1 15212123 1 1501208602 1
23 Step Motor 15212123 1 15212123 1 15212404 1
24
Shield Cover of Electric
Box
01592084 1 01592084 1 01592084 1
25 Electric Box Cover 2012240903 1 2012240903 1 2012240903 1
26 Terminal Board 42011233 1 42011233 1 42011233 1
27 Jumper 4202300107 1 4202300108 1 4202300115 1
28 Main Board 30148296 1 30148296 1 30148469 1
29 Electric Box Assy 20302492 1 20302490 1 20302705 1
30 Rear Grill 01472029 1 01472029 1 01472028 1
31 Rear Grill 01472030 1 01472030 1 01472030 0
32 Electric Box Cover2 2012207504 1 2012207504 1 2012214207 1
33 Screw Cover 24252016 1 24252016 1 24252016 3
34
Ambient Temperature
Sensor
390000451 1 390000451 1 390000451 1
35 Temperature Sensor 390000598 1 390000598 1 390000598 1
36 Remote Controller 30510138 1 30510138 1 30510138 1
