Super Free Match
Service Manual
MAINTENANCE
N
161
GWH24TD-D3DNA1A/I
Part list:
GWH24TD-D3DNA1A/I for CB148N03800
NO. Description
GWH24TD-D3DNA1A/I
Code Qty
1 Front Panel 20012894U 1
2 Filter Sub-Assy 11122136 2
3 Screw Cover 242520053 4
4 Front Case Sub-assy 20022004 1
5 Guide Louver 10512236 1
6 Guide Louver (small) 1051223701 1
7 Swing Lever 2
1058211601
1
8 Air Louver 10512252 15
9 Left Axile Bush 1051203701 2
10 Water Tray Assy 01272119 1
11 Rear Case assy 22202092 1
12 Cross Flow Fan 10352420 1
