A/A DC INVERTER U-MATCH AIR CONDITIONERS MAINTENANCE
208
Removal and Assembly
Step Illustration Handling Instruction
7．Tighten the screws
fixing the motor
●Use screwdriver to tighten the
screws fixing the motor.
8．Mount the fan and
tighten the fixing
bolts
●Mount the fan and use
spanner to tighten the bolts
fixing the fan.
9 ． Mount the water
tray and tighten
the screws
●Use screwdriver to loosen the
screws fixing the water tray
emoval and Installation of Drainage Pump
Step Illustration Handling Instruction
1．Loosen the screws
fixing the water tray
●Use screwdriver to loosen the
screws fixing the water tray
2. Remove the water
tray
●Remove the water pump and
replace it.
To Next Page
