Service Manual
Installation and Maintenance
49
NO.
Description
Part Code
QtyETAC2-12HP230VA-A ETAC2-15HP230VA-A
Product Code CC060045400_L45468 CC060045600_L45468
1 Temp Sensor Sleeving 05212423 05212423 1
2 Temperature Sensor 390000372 390000372 1
3 Condenser Assy 01100200322 01100200323 1
4 Axial Flow Fan 10331004 10331004 1
5 Fan Motor 15011803 1501180310 1
6 Connection Board 01381021 01381021 2
7 Diversion Circle 10371218 10371218 1
8 Flow Guide Loop 1037121907 1037121904 1
9 Top Cover Sub-Assy 0125104201P 0125104201P 1
10 Clapboard Sub-Assy 0123111901 0123111901 1
11 Cable Clamp 71000151 71000151 2
12 Door Thread 02161505 02161505 1
13 Hand Lever 26231156 26231156 1
14 Hand Lever 26231157 26231157 1
15 Outer Support Sub-assy(Left) 01701038 01701038 1
16
Bafe Plate 01361018
01361018
1
17 Helicoid Tongue 02121029P 02121029P 1
18 Rear Grill 01471007 01471007 1
19
Temperature Sensor 390001982 390001982 1
20 Air Duct Sub-assy 01221027P 01221027P 1
21 Bearing Holder Sub-assy 26151139 26151139 1
22 Bearing Holder 26151138 26151138 1
23 Electric Heater 32001039 32001039 1
24 Evaporator Assy 01100100041 01100100041 1
25 Ambient Temperature Sensor 3900012123 3900012123 1
26 Air Outlet Grille 22411023 22411023 1
27 Front Panel 20001673 20001673 1
28 Front Panel Clip 02111013 02111013 2
29 Filter Sub-Assy 11121212 11121212 2
30 LCD Cover Sub-assy 2016138202 2016138202 1
31 Membrane 6306130903 6306130903 1
32 Display Board 30562073 30562073 1
33 Filter 11120037 11120037 1
34 Remote Control Cover 20121070T 20121070T 1
35 Front Panel Assy 2000147503 2000147503 1
36 Supporting Board 26111167 26111167 1
37 Main Board 1 30132232 30132232 1
38 Supporting Board 26111166 26111166 1
39 Main Board 2 30132161 30132161 1
40 Temp Sensor Sleeving 05212423 05212423 1
41 Temperature Sensor 390000596 390000596 1
42 Air Flue Assy 0122102602 0122102602 1
43 Heater Wiring Block Board 02111009 02111009 1
44 Cross Flow Fan 10351004 10351004 1
45 Motor Support Sub-Assy 01701014P 01701014P 1
46 Retaining Plate of Condenser 01741023 01741023 1
To Next Page
