Service Manual
Installation and Maintenance
50
47 Fan Motor 1501180213 1501180213 1
48 Clapboard 0123115801 0123115801 1
49 4-Way Valve 430004032 430004032 1
50 4-Way Valve Assy 03015200051 03015200091 1
51 Outer Support Sub-assy(Right) 01701039 01701039 1
52 Cable Cross Plate 26111215 26111215 1
53 Filter Sub-Assy 11121607 11121607 1
54 Air Inlet Door 01441018P 01441018P 1
55 One Way Valve 07133001 07133001 1
56 Capillary Sub-assy 03000600252 03000600253 1
57 Magnet Coil 4300040022 4300040022 1
58 Compressor Overload Protector(Internal) 00180240 / 1
59 Compressor Gasket 76710287 76710287 3
60 Compressor and Fittings 00101350 00101348 1
61 Drainage Valve 07101001 07101001 1
62 Chassis Sub-assy 01201241P 01201241P 1
63 Foam (Water Tray) 12311048 12311048 1
64 Electric Box Assy 10000200006301 10000200006301 1
65
Junction box
/
/
/
66 Junction lid / / /
67 Relay 4402033402 4402033402 1
68 Capacitor CBB65 3300008101 3300008101 1
69 Transformer 43110270 43110270 1
70 Capacitor CBB61S 3301074710 3301074710 1
71 Capacitor CBB61 3301074716 3301074716 1
72 Terminal Board 42011103 42011103 2
73 Radiator 49010252 49010252 1
74 Fuse 46010055 46010055 1
75 Wiring Terminal 42010039S 42010039S 1
76 Wiring Terminal 42010037 42010037 1
77 Pwer cord (LCDI) / / /
Above data is subject to change without notice.
To Next Page
