12
GREEN STAR ASSEMBLY
(Cont’d)
3. Slide the desired Screen or Blank over
the Twin Gears and into the Twin Gear
Housing.
4. Slide the Pulp Discharge Casing over
the Twin Gear Housing.
5. Close each Latching Arm and tighten by
turning both Latching Arm Knobs
clockwise.
6. Attach the Outlet Adjusting Knob by
inserting it into the Pulp Discharge
Casing and turning it clockwise until it is
snug. Do not over tighten.
7. Attach the Safety Tray to the Feeding
Chute.
