13
Safety Reminder: Make sure to unplug from the outlet before disassembly
GREEN STAR DISASSEMBLY
1. Remove the Safety Tray by lifting it
vertically from the Feeding Chute.
2. Turn the Outlet Adjusting Knob counter-
clockwise until it separates from its
threads; then pull it out from its grooves.
3. Turn the Latching Arm Knobs counter-
clockwise to loosen. Open the Latching
Arms horizontally outward on their hinges.
4. Remove the Pulp Discharge Casing.
To Next Page
