Microprocessor Controller for DOAS50
®
Al_MOP_A_EVD_1.
Active
EVD Max Operating
Pressure Alarm - Valve 1
(0=Normal 1=Alarm)
Alarm Normal 612 BV
ReadCOV_
NoWrite
0 10562 Discrete
Al_S1_EVD_1.Active
EVD-S1 Suction Pressure
Sensor Alarm (0=Normal
1=Alarm)
Alarm Normal 614 BV
ReadCOV_
NoWrite
0 10564 Discrete
Al_S2_EVD_1.Active
EVD-S2 Suction
Temperature Sensor Alarm
(0=Normal 1=Alarm)
Alarm Normal 615 BV
ReadCOV_
NoWrite
0 10565 Discrete
Al_S4_EVD_1.Active
EVD-S4 Discharge
Temperature Sensor Alarm
(0=Normal 1=Alarm)
Alarm Normal 617 BV
ReadCOV_
NoWrite
0 10567 Discrete
Al_SuctHiP_COMP_1.
Active
Compressor Envelope -
SuctHiP_COMP (0=Normal
1=Alarm)
Alarm Normal 618 BV
ReadCOV_
NoWrite
0 10568 Discrete
Al_SuctLowP_
COMP_1.Active
Compressor Envelope
- SuctLowP_COMP
(0=Normal 1=Alarm)
Alarm Normal 619 BV
ReadCOV_
NoWrite
0 10569 Discrete
Comp_Staging_Order_
Skipped.Active
Compressor Staging
Order is Skipped Warning
(0=Normal 1=Alarm)
Alarm Normal 632 BV
ReadCOV_
NoWrite
0 10580 Discrete
EVD_PrePosition_
Alarm_1.Active
Unexpected EEV Position
(0=Normal 1=Alarm)
Alarm Normal 634 BV
ReadCOV_
NoWrite
0 10582 Discrete
ER_Wheel_High_
DP.Active
Energy Recovery Wheel
high differential pressure
(0=Normal 1=Alarm)
Alarm Normal 731 BV
ReadCOV_
NoWrite
0 10679 Discrete
Binary Values - Commandable
Aux_BMS_Digital_
Output_1
BMS Commanded auxilary
digital output
Active Inactive 207 BV
ReadCOV_
Commandable
0 24 Coil
Aux_BMS_Digital_
Output_2
BMS Commanded auxilary
digital output
Active Inactive 208 BV
ReadCOV_
Commandable
0 25 Coil
Aux_BMS_Digital_
Output_3
BMS Commanded auxilary
digital output
Active Inactive 209 BV
ReadCOV_
Commandable
0 26 Coil
Aux_BMS_Digital_
Output_4
BMS Commanded auxilary
digital output
Active Inactive 210 BV
ReadCOV_
Commandable
0 27 Coil
Aux_BMS_Digital_
Output_5
BMS Commanded auxilary
digital output
Active Inactive 211 BV
ReadCOV_
Commandable
0 28 Coil
Aux_BMS_Digital_
Output_6
BMS Commanded auxilary
digital output
Active Inactive 212 BV
ReadCOV_
Commandable
0 29 Coil
Integer Values - Read Only
Allow_Fan_Delay_
Remaining
Startup Sequence Fan
Damper Delay. Time before
enabling Fan startup
sequence.
1IV
ReadCOV_
NoWrite
1 30181 Input 2
Supply_Fan_Delay_
Remaining
Supply Fan startup
sequence. Time before
starting supply fan.
2IV
ReadCOV_
NoWrite
1 30183 Input 3
Exhaust_Fan_Delay_
Remaining
Exhaust Fan startup
sequence. Time before
starting exhaust fan.
3IV
ReadCOV_
NoWrite
1 30185 Input 4
LatestAlm
Most recent alarm. See
alarm table.
7IV
ReadCOV_
NoWrite
1 30193 Input 5
Appendix: Points List
VARIABLE DESCRIPTION
ACTIVE
TEXT
INACTIVE
TEXT
BACNET MODBUS
OBJECT
INSTANCE
OBJECT
TYPE
ACCESS HYST INDEX
REGISTER
TYPE
SIZE
