Greenlee Textron / Subsidiary of Textron Inc.
21
4455 Boeing Dr., Rockford, IL 61109-2988 815/397-7070
853 Quad Bender™
Bending Tables (cont’d)
1-1/2" IMC, Steel Rigid and Aluminum Rigid
Y 15 4.75 12.48 20.21 27.93 35.66 47.25 58.84 82.03 128.39
L1 15 7.71 15.44 23.17 30.90 38.62 46.35 57.94 69.53 92.72 139.08
L2 15 9.95 17.68 25.40 33.13 40.86 48.58 60.18 71.77 94.95 141.31
Z 15 15.62 23.08 30.55 38.01 45.48 52.94 64.14 75.33 97.73 142.51
MINIMUM H = 2.11
Y 22.5 0.36 5.59 10.82 16.04 21.27 29.11 36.95 52.63 83.98
L1 22.5 5.18 10.41 15.64 20.86 26.09 31.31 39.15 46.99 62.67 94.03
L2 22.5 8.53 13.76 18.98 24.21 29.44 34.66 42.50 50.34 66.02 97.38
Z 22.5 14.13 18.96 23.79 28.62 33.45 38.27 45.52 52.76 67.24 96.22
MINIMUM H = 3.56
Y 30 1.90 5.90 9.90 13.90 19.90 25.90 37.90 61.90
L1 30 7.90 11.90 15.90 19.90 23.90 29.90 35.90 47.90 71.90
L2 30 12.36 16.36 20.36 24.36 28.36 34.36 40.36 52.36 76.36
Z 30 17.41 20.87 24.34 27.80 31.27 36.46 41.66 52.05 72.83
MINIMUM H = 5.24
Y 45 0.53 3.36 6.18 10.43 14.67 23.15 40.12
L1 45 10.95 13.78 16.60 20.85 25.09 33.57 50.54
L2 45 17.65 20.47 23.30 27.55 31.79 40.27 57.24
Z 45 20.98 22.98 24.98 27.98 30.98 36.98 48.98
MINIMUM H = 9.18
Y 60 1.92 5.39 8.85 15.78 29.64
L1 60 12.94 16.40 19.87 26.80 40.65
L2 60 21.87 25.34 28.80 35.73 49.58
Z 60 22.69 24.42 26.15 29.62 36.54
MINIMUM H = 13.65
Y90 2.61 8.61 20.61
L1 90 14.34 20.34 32.34
L2 90 27.74 33.74 45.74
Z90 22.97 22.97 22.97
MINIMUM H = 22.97
2" IMC, Steel Rigid and Aluminum Rigid
Y 15 3.46 11.18 18.91 26.64 34.36 45.96 57.55 80.73 127.09
L1 15 7.71 15.44 23.17 30.90 38.62 46.35 57.94 69.53 92.71 139.08
L2 15 10.14 17.87 25.60 33.32 41.05 48.78 60.37 71.96 95.14 141.51
Z 15 16.10 23.56 31.03 38.49 45.95 53.42 64.61 75.81 98.20 142.99
MINIMUM H = 2.23
Y 22.5 4.54 9.77 14.99 20.22 28.06 35.90 51.58 82.93
L1 22.5 5.18 10.40 15.63 20.86 26.08 31.31 39.15 46.99 62.67 94.02
L2 22.5 8.82 14.05 19.28 24.50 29.73 34.95 42.79 50.63 66.31 97.67
Z 22.5 14.71 19.54 24.37 29.20 34.02 38.85 46.09 53.34 67.82 96.79
MINIMUM H = 3.78
Y 30 0.95 4.95 8.95 12.95 18.95 24.95 36.95 60.95
L1 30 7.89 11.89 15.89 19.89 23.89 29.89 35.89 47.89 71.89
L2 30 12.74 16.74 20.74 24.74 28.74 34.74 40.74 52.74 76.74
Z 30 18.09 21.55 25.02 28.48 31.95 37.14 42.34 52.73 73.52
MINIMUM H = 5.58
Y 45 2.43 5.26 9.50 13.74 22.23 39.20
L1 45 10.91 13.74 16.57 20.81 25.06 33.54 50.51
L2 45 18.20 21.03 23.86 28.10 32.34 40.83 57.80
Z 45 21.88 23.88 25.88 28.88 31.88 37.88 49.88
MINIMUM H = 9.81
Y 60 0.94 4.40 7.87 14.79 28.65
L1 60 12.86 16.32 19.79 26.72 40.57
L2 60 22.58 26.04 29.50 36.43 50.29
Z 60 23.83 25.56 27.30 30.76 37.69
MINIMUM H = 14.64
Y90 1.34 7.34 19.34
L1 90 20.02 32.02
L2 90 34.59 46.59
Z90 24.75 24.75
MINIMUM H = 24.27
DIM ANGLE 2" 4" 6" 8" 10" 12" 15" 18" 24" 36"
