853 Quad Bender™
BENDING CONDUIT
1. Plug the cord into an appropriate receptacle. See
Grounding Instructions.
2. Turn the circuit breaker (ON/OFF switch) to ON.
3. Press BEND or UNLOAD until the shoe is 5° to 10°
before the 0° starting point.
4. Load the conduit so that the bending mark is
aligned with the front edge of the shoe hook.
Operation
Pinch points:
Keep hands away from bending
shoe, rollers and conduit when
bender is in use.
Do not operate the bender while wearing loose
clothing. Loose clothing can get caught in moving
parts.
Failure to observe this warning can result in severe
injury or death.
Wear eye protection when operating
or servicing this tool.
Failure to wear eye protection can
result in serious eye injury from
flying debris.
Loading the Conduit
5. Refer to the instruction decal for the appropriate
bend angle.
To Next Page
