10 ACCESSORIES
Theoperatormustuseaccessories/toolsthatwereclearedbyBSCforusewiththelasersystem.BSCassumesnoliabilityandwarrantyfordamage
andconsequentialdamagewhenusingthelasersystemwithnon-qualifiedaccessories/tools.ContactBSCforanup-to-datelistofaccessories/
tools for the GreenLight XPS™ Laser System.
10.1 Video Camera Insert
A video camera insert must be inserted between the telescope and the camera (unless a comparable camera insert is built into the telescope).
Thevideocamerainsertshaveanopticaldensity(OD)of5atawavelengthof532nm.Thisblocksmostofthelaserlight,preventingsaturationof
the video camera sensor. The optimum transmission at wavelengths other than 532 nm and the video camera insert diameter depends on the video
camera and telescope model.
10.2 Laser Protective Eyewear
Eyewearhasbeendesignedtoprotectoperatingroompersonnelfromthe532nmlaserenergy.Theeyewearhasaminimumopticaldensity(OD)
of6.0at532nm.TheeyewearrequirementsforEUare532DL6.
• Physicianprotectiveeyewear—Theessentiallyclearlensmaterialhashighvisiblelighttransmissionandminimalcolordistortion.
• Spectatorprotectiveeyewear—Althoughithasgoodvisiblelighttransmission,theorangecoloroftheplasticlenscausessomecolor
distortion.
11 INSTALLATION
This section provides general guidelines for the installation of the laser system. This laser system has specific installation requirements. It is the
user’s responsibility to fulfill these requirements before the installation of the laser system. Improper installation can result in intermittent operation
and even damage to the laser system. Please read the below information carefully.
11.1 Responsibility of BSC
A BSC service representative will install the laser system. Upon arrival at the installation site, the representative will perform the following:
1. Verify appropriate electrical power is available.
2. Remove the console from the crate and inspect for damage.
3. Perform all optical, electronic, and system checks necessary to bring the laser into operation.
4. Inventory all shipped accessories.
11.2 Responsibility of Customer
Provisions for proper power must be made before the receipt and installation of the laser system. Return visits by service personnel for installation
will not be covered under warranty. The customer should complete the Installation Checklist and return it to BSC or distributor. Upon completion of
the pre-installation site preparation, contact BSC or the distributor to check shipment date and schedule installation of the system.
The laser system uses standard electrical service and has built-in cooling systems; therefore, installation requires minimal site preparation.
11.3 Positioning of the Console
The console must be positioned not more than 5 ft (1.5 m) from the centerline of the treatment table to ensure proper handling of the fiber.
Position the console at least 1 ft (0.3 m) from the wall for proper ventilation during use.
11.4 Power Requirements
ThepowersourcefortheGreenLightXPSLaserSystemmustbeasingle-phaseservicewithvoltagebetween200to240VAC,50/60Hz,current≤20Amp
*
. The
laser will automatically adjust to the voltage and frequency within this range. The laser can function when some voltage change is present in the
service line; however, the voltage may not vary by more than ± 10 %.
For BSC to provide the correct electrical plug, the customer must provide information about the installed receptacle in the facility to BSC before
installation.Any250VAC,current≤20Amp
*
, two poles, three wire receptacle can be used if it meets the system’s electrical requirements; meets
facility, city, county, state, and country ordinances; and complies with EN 60601 for leakage current.
It is recommended the GreenLight XPS Laser System use a dedicated circuit breaker with a minimum rating of 16 Amp or higher to ensure normal
operation.
* The 20 Amp rating indicates the current rating that the power source is expected to be capable of supplying to operate the laser at the maximum rated power output of 180 W. The 20 A
rating is neither the minimum nor maximum operational main current requirement; it is a current in which internal circuitry protects the GreenLight XPS Laser System in an over-current
condition.
