GREENLINE 33 - Page 72

Greenline 33 65
F45
Inverter/charger
From LiPo battery via S6 via F47
48
100
ANL
F46
Hybrid control unit
Main HCU fuse
48
355
ANL
F47
LiPo battery bank
Main LiPo battery fuse
48
300
ANL
F48
Radio memory
From service bat. directly via F30
12
5
ATO
F49
Diesel heater controls
From service bat. directly via F30
12
5
ATO
F50
Defroster
From service bat. via S3 via F32
12
30
ATO
K3
Hybrid cooling pump
From F21 (control from engine key
switch #201)
12
30
Relay
K4
Engine blower
From F23 (control from engine key &
hybrid switch (D) #200)
12
30
Relay
K5
Defroster
From F50 (control from defroster
switch on console #95)
12
40
Relay
K6
Solar panels
From F40 to LiPo battery
24
40
Relay
K7
Solar panels
From F40 to LiPo battery
24
40
Relay
