GREENLINE 33 - Page 71

Greenline 33 64
F7
Sump box pump, Grey water
pump
From service bat. via S3 via F32
12
16
CB
F10
Wiper/sliding roof
From service bat. via S3 via F32
12
10
CB
F11
Cockpit lights
From service bat. directly via F30
12
10
CB
F12
12V fridge
From service bat. via S3 via F32
12
16
CB
F13
Radio/socket 12V
From service bat. via S3 via F32
12
10
CB
F14
Instruments, instruments
illumination
From service bat. via S3 via F32
12
32
CB
F16
Autopilot
From service bat. via S3 via F32
12
10
CB
F17
Bilge pump
From service bat. directly via F30
12
10
CB
F20
Diesel heater
From service bat. directly via F30
12
16
CB
F21
Clutch actuator, cooling pump
From engine bat. via S1 via F26
12
16
CB
F23
Engine blower
From engine bat. via S1 via F26
12
10
CB
F24
12V charger
From 12V charger to diode splitter
12
35
ANL
F26
Engine consumers
From engine bat. via S1 via F27
12
35
ANL
F27
Engine battery
Main engine battery fuse
12
355
ANL
F28
Diode splitter
From diode splitter to engine battery
12
125
ANL
F29
Diode splitter
From diode splitter to service battery
12
125
ANL
F30
24h consumers, swimming
platform
From service battery directly via F31
12
35
ANL
F31
Service battery
Main service battery fuse
12
200
ANL
F32
Service consumers
From service bat. via S3 via F31
12
80
ANL
F33
Anchor winch
From borthruster battery via S4 via F37
12
80
RCCB
F34
Anchor winch commands
From borthruster battery via S4 via F37
12
ATO
F36
Diode splitter
From diode splitter to bowthruster
battery
12
125
ANL
F37
Bowthruster battery
Main bowthruster battery fuse
12
250
ANL
F38
Shore power
Main shore power fuse
230ac
16
RCCB
F39
General RCCB
From inverter or F38; main consumers
fuse
230ac
16
RCCB
F40
Battery charger 12V
From F39
230ac
10
CB
F41
Water heater
From F38
230ac
16
CB
F42
Sockets/ air cond.
From F39
230ac
16
CB
F44
Solar panels
From solar panels to LiPo battery via
relays K6 & K7
48
35
ANL
